Nisshinbo NJM2769BM 2-Channel Stereo Headphone Amp CD-ROM 2.8V to 5.5V 2mA 6dB

Gain: 6 dB

Class: Other

Width: 5 mm

Height: 1.6 mm

Length: 5 mm

Input Type: Single

Supply Type: Single

Output Power: 100 mW

Mounting Style: SMD/SMT

THD plus Noise: 0.02 %

Number of Channels: 2 Channel

Output Signal Type: Single

Description/Function: Headphone

Supply Current - Max: 4 mA

Supply Voltage - Max: 5.5 V

Supply Voltage - Min: 2.8 V

Audio - Load Impedance: 32 Ohms

Pd - Power Dissipation: 375 mW

Operating Supply Current: 2 mA

Operating Supply Voltage: 5 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
