Optical System: Infinite Optical System
Viewing Head: Seidentopf Binocular Viewing Head, Inclined at 45°, 360° Rotatable, Interpupillary 48-75mm
Eyepiece: Ф30 Wide Field Eyepiece WF10×/22, Eyepiece Tube Diameter 30mm
Objective
Infinite Plan Achromatic Objective 4×/0.10 WD=22
LWD Infinite Plan Achromatic Phase Objective
10×/0.25 WD=6
20×/0.4 WD=3.1
40×/0.55 WD=2.2
Nosepiece: Backward Quintuple Nosepiece
Condenser: ELWD Condenser NA0.3,LWD72mm(without Condenser 150mm)
Centering Telescope: Centering Telescope(φ30mm)
Phase Annulus: 10×, 20×, 40×Phase Annulus Plate (Adjustable)
Stage
Plain Stage 230×170
Glasse Insert
Attachable Mechanical Stage, X, Y Coaxial Control, Moving Range 80×120mm
Auxiliary Stage
Terasaki Holder
Petri Dish Holder φ38
Petri Dish Holder φ54
Focusing System: Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Moving Range up 4.5mm down 4.5mm
Illumination: 6V30W Halogen Lamp, Brightness Adjustable
Filter: Blue, Green and Ground Glass,Diameter 45mm
