Weight: 114 g
Accuracy: ± 0.25 %
Input Type: Thermocouple, RTD, Thermistor
Form factor: 1/16 DIN
Front Bezel: 48 mm²
Display Size: 6.35 mm (.25 in)
Display Type: 4 Digit LED
Accuracy Note: ± 0.25% span, ± 1 least significant digit
Memory Backup: Non-Volatile
Output Detail: DC Pulse;SPST, 5A @ 250 Vac resistive
Output Signal: DC Pulse
Control Output: SPST Relay
Data Interface: RS485 Modbus
Supply Voltage: 100 to 240 Vac
Measuring Range: Type B : 100 to 1800°C, Type S : 0 to 1700°C, Type R : 0 to 1700°C, Type N : -200 to 1300°C, Type E : 0 to 600°C, Type T : -20 to 400°C, -200 to 400°C, Type J : -20 to 400°C, -100 to 850°C, Type K : 200 to 1300°C, -200 to 500°C, Type L : -200 to 500°C, Type U : -200 to 800°C, RTD : 0 to 100°C, -20 to 500°C, -200 to 600°C
Measurement Type: Temperature
Number of Inputs: 1
Display Type Note: 3.5 Digit Dual Display, Two 4-digit, 7 segment 6.35 mm H (0.25") LEDs PV: Red SV: Green
Enclosure Ratings: IP66
Supply Power Note: 100 to 240 Vac, 50/60 Hz
Supply Power Type: AC
Depth Behind Panel: 80 mm
Panel Thickness, Max: 9.5 mm
Number of Control Outputs: 1
Operating Temperature, Max: 50 °C
Operating Temperature, Min: 0 °C
