Height: 90 mm
Length: 35 mm
Stability: ≤0.1% FS/year
Display Type: LCD
Accuracy Note: ± 0.25% for gauge pressure >5ps
Pressure Type: Gauge
Pressure, Max: 5 psi
Pressure, Min: 0 psi
Accuracy Class: 0.1% to 0.25%
Burst Pressure: 4x Full Scale
Outer Diameter: 65 mm
Proof Pressure: 200% Full Scale
Supply Voltage: 9 Vdc
Number of Digits: 4
Enclosure Ratings: IP65, IP68
Materials, Wetted: 316 Stainless Steel
Pressure Accuracy: ± 0.25 %
Relative Humidity: ≤90%
Supply Power Type: Battery
Sample/Display Rate: ≤4 times/second
Display Measuring Units: bar, kg /cm2, kPa, MPa, psi
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -20 °C
