OMEGA DRC-8906 DIN Rail Temperature, Voltage/Current Signal Conditioners (Current, 4 to 20 mA)

CMRR: 85 dB

Width: 22.5 mm

Height: 110 mm

Length: 77 mm

Weight: 142 g

Accuracy: ± 0.1 %

Mounting: DIN Rail Mount

Isolation: 700 V

Linearity: ±0.02%

Materials: Plastic

Input Type: Current

Output Value: Process

Output Signal: Voltage

Response Time: 10 ms (10 to 90%)

Supply Voltage: 22 to 26 Vdc

Impedance Input: Voltage: 1 MΩ minimum, Current: 50 Ω typical

Load Resistance: 0 to 500 Ω

Input Range Note: Maximum Input: Voltage input models, 130 VRMS; current input models, 65 mA (3.25 volts across 50 Ω input resistance)

Number of Inputs: 1

Supply Power Note: 22 to 26 Vdc (unregulated); 15 mA (models DRC-8920/21/40/41/42), 20 mA

Supply Power Type: DC

Open_Circuit Voltage: 13 V

Voltage Output Range: 0 to 10 V

Additional Features 1: Slim Housing Mounts on DIN Rail

Temperature Coefficient: Zero, ±0.5 mV/°C (0 to 10 V output models), ±0.5 microamp/°C (4 to 20 mA output models); full scale, ±100 ppm/°C typical

Storage Temperature, Max: 80 °C

Storage Temperature, Min: -40 °C

Current Measurement Range: 4 to 20 mA

Operating Temperature, Max: 55 °C

Operating Temperature, Min: 0 °C
