Width: 6.1 mm
Height: 113 mm
Length: 115 mm
Weight: 70 g
Accuracy: ± 0.05 %
Mounting: DIN Rail 35 mm Standard, EN 60715
Approvals: CE, UL, RoHS
Stability: Load Stability: ≤0.01% of span/100 Ω
Input Type: RTD
Wire Gauge: 26 to 13 AWG
EMC Standard: NAMUR NE 21
Installation: Pollution degree 2 and measurement/overvoltage category II
Output Value: Process
Accuracy Note: Better than 0.2°C or ±0.1% of selected range
Output Detail: Current: Range Limits(NAMUR NE43 Out of Range):Below 3.8 mA or above 20.5 mA for 4 to 20 mA output; 0 mA or above 20.5 mA for 0 to 20 mA output Sensor Error Detection(Dip Switch Selectable for Enable or None): Below 3.5 mA or above 23 mA for 4 to 20 mA output; 0 mA or above 23 mA for 0 to 20 mA output Incorrect DIP-Switch Setting Identification: Below 3.5 mA or above 23 mA for 4 to 20 mA output; 0 mA or above 23 mA for 0 to 20 mA output Output Error Level: DIP switch selectable for upscale or downscale. Voltage: Range Limits (Out of Range):Range ±2.5% Sensor Error Detection (Dip Switch Selectable for Enableor None): 0V or selected range + 10% Incorrect DIP-Switch Setting Identification: 0V Output Error Level: DIP switch selectable for upscale or downscale
Output Signal: Current, Voltage
Response Time: < 30 ms
LED Indicators: Green LED indicates operational status of the unit and input sensor
Supply Voltage: 16.8 to 31.2 Vdc
Load Resistance: Current: 21 mA/600Ω /12.6V max;Voltage:>10 kΩ min
Input Range Note: Sensor Current, RTD: <150 µA;Sensor Cable Specifications: 50 Ωper wire or 50 nF;Effect of Sensor Cable Resistance (3 or 4-wire RTD): <0.002 Ω/Ω;Broken Sensor Detection: >800 Ω;Shorted Sensor Detection: <18 Ω
Number of Inputs: 1
EMC Immunity Note: NAMUR NE 21, A Criterion, Burst: <±1% of span (span = selected input range)
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP20
Noise Calibration: >60 dB
Power Consumption: 0.7 W, Internal - 0.65 W
Relative Humidity: 0 to 95% RH (non-condensing)
Supply Power Note: 16.8 to 31.2 Vdc via power rail or connectors
Supply Power Type: DC
Response Time Note: Response Time (0 to 90%, 100 to 10%): <30 ms/300 ms (selectable, provides either fast response or signal dampening as needed)
Voltage Output Range: 0 to 10 Vdc
Screw Terminal Torque: 0.5 Nm
Temperature Coefficient: ≤±0.02°C/°C
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -40 °C
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -25 °C
Calibration Temperature, Max: 28 °C
Calibration Temperature, Min: 20 °C
