Weight: 0 lb
Accuracy: ± 1 %
Approvals: CE
Materials: Aluminum, Bronze, Brass
Conductivity: > 20 µS/cm
Accuracy Note: ± 1% of full scale
Output Detail: Square wave pulse, opto isolated, 550 Hz @ 20 ft/second 6 mA maximum, 30 Vdc forward flow standard (reverse flow optional)
Output Signal: DC Pulse
Velocity, Max: 20 ft/s
Velocity, Min: 0.28 ft/s
Insertion Type: Standard
Pipe Size, Max: 10 in
Pipe Size, Min: 3 in
Supply Voltage: 12 to 24 Vdc
Materials, Wetted: Brass, EPDM, Hastelloy, PVDF
Number of Outputs: 1
Supply Power Note: 12 to 24 Vdc, 250 mA
Supply Power Type: DC
Media Compatibility: Acid Solutions, Conductive Liquids, Saltwater
Empty Pipe Detection: Defaults to zero flow
Operating Pressure, Max: 200 psi
Process Connection Size: 1 1/2 in
Process Connection Type: NPT Male
Process Temperature, Max: 93 °C
Process Temperature, Min: 0 °C
Volumetric Flow Rate, Max: 4895 GPM
Volumetric Flow Rate, Min: 69 GPM
Operating Temperature, Max: 72 °C
Operating Temperature, Min: -17 °C
Material Construction Option: Brass
