OMEGA HX85BA Wall, Remote, or Duct Mt. Temp, RH, Dew Pt, or BP Transmitters (3/4 in, 0 to 10 Vdc, RS232)

Filter: Sinter Stainless Steel

Weight: 0.9 kg

Accuracy: ± 0.5 °C (± 0.9 °F)

Cable Length: 1.8 m

Current, Max: 50 mA

Probe Length: 203 mm

Pressure Note: 317 kg (700 lb) (47.6 bar)

Pressure, Max: 1100 mBar

Pressure, Min: 750 mBar

Time Constant: <15 sec, air flow dependent (for 66.6% response)

Data Interface: RS232

Probe Diameter: 19 mm

Supply Voltage: 18 to 30 Vdc

Pressure Limits: Up to 690 psi

Sensor Material: Stainless Steel

Measurement Type: Temperature, Humidity, Barometric Pressure

Electrical Output: 0 to 10 Vdc

Relative Humidity: 5 to 95%

Data Interface Note: RS232C (bi-directional) to DTE device, 19.2 kilo baud, 8 bits data, 1 stop bit, no parity

Mounting Orientation: Remote Mount

Process Connection Size: 3/4 in

Process Connection Type: NPT Male and Female

Relative Humidity Accuracy: ± 1.0 % RH

Temperature Measurement, Max: 120 °C

Temperature Measurement, Min: -20 °C
