Width: 0.93 in
Height: 1 in
Length: 1.75 in
Linearity: ± 0.1%
Materials: 17-4 PH Stainless Steel
Force Type: Compression, Tension
Hysteresis: ± 0.15%
Cable Length: 12 ft
Overload, Max: 300% FS
Repeatability: ± 0.05%
Safe Overload: 150% FS
Load Cell Type: Pancake
Supply Voltage: 10 Vdc
Input Resistance: 360 Ω min
Electrical Output: 2 mV/V
Enclosure Ratings: IP54
Output Resistance: 350 ± 10 Ω
Supply Power Note: 10 Vdc, 15 Vdc maximum
Calibration Option: 5 POINT NIST
Load Cell Capacity: 500 lbF
Zero/Balance Error: ± 1%
5-Point Calibration: 0%, 50%, 100%, 50%, 0%
Thermal Span Effect: ± 0.005% FSO/°F
Thermal Zero Effect: ± 0.005% FSO/°F
Through Hole Thread: 3/8"-24 UNF
Electrical Connection: Cable
Full Scale Deflection: 0.003 in
Wiring/Connector Table: Green: (+) Output; White: (-) Output; Black: (-) Input; Red: (+) Input
Process Temperature, Max: 71 °C
Process Temperature, Min: 16 °C
Operating Temperature, Max: 82 °C
Operating Temperature, Min: -40 °C
