Width: 0.5 in
Height: 0.98 in
Length: 2.38 in
Linearity: ± 0.03%
Materials: Aluminum
Force Type: Compression, Tension
Hysteresis: ± 0.02%
Cable Length: 10 ft
Overload, Max: 300% FS
Repeatability: ± 0.01%
Safe Overload: 150% FS
Load Cell Type: Bending Beam
Supply Voltage: 10 to 15 Vdc
Creep in 20 min: ± 0.03%
Input Resistance: 350 +50/-3.5 Ω
Electrical Output: 3 mV/V
Enclosure Ratings: IP67
Output Resistance: 350 ± 3.5 Ω
Supply Power Note: 10 Vdc, 15 Vdc maximum
Calibration Option: NIST
Load Cell Capacity: 250 lbF
Zero/Balance Error: ± 1%
Thermal Span Effect: ± 0.0008% FS/°F
Thermal Zero Effect: ± 0.0015% rdg/°F
Electrical Connection: Cable
Process Temperature, Max: 65 °C
Process Temperature, Min: -15 °C
Operating Temperature, Max: 90 °C
Operating Temperature, Min: -55 °C
