Weight: 0.45 kg
Display: Yes
Laser Power: <1 mW
Weight Note: 0.45 kg (12 oz) sensing head; 1.2 kg (42.3 oz) plastic case
Cable Length: 4.5 m
Laser Output: false
Accuracy Note: ± 1% rdg or 1.7°C (3°F),whichever is greater; 25°C ambient, 0.95 emissivity
Field of view: Spot size 25.4 @ 914 mm
Housing Width: 80 mm
Output Detail: 1 mV/degree, 0 to 5 Vdc or 4 to 20 mA
Output Signal: Current
Repeatability: ± (1% rdg + 1 digit)
Response Time: 100 ms
Sensor Length: 109 mm
Data Interface: RS232
Housing Height: 51 mm
Housing Length: 120 mm
Supply Current: 80 mA
Supply Voltage: 8 to 24 Vdc
Emissivity Note: 0.10 to 1.00 in 0.01 steps
Emissivity, Max: 1
Emissivity, Min: 0.1
Sensor Diameter: 41 mm
Housing Material: Plastic
Enclosure Ratings: IP65, NEMA Type 4
Intrisically Safe: None
Response Time Note: 100 ms, 0 to 63.5% of final value
Laser Beam Diameter: 5 mm
Laser Classification: Class 2
Enclosure Ratings Note: NEMA 4 (IP65); sensor head and plastic or aluminum electronics enclosure
Laser Wavelength Color: 650 nm
Spectral Response, Max: 14 μm
Spectral Response, Min: 8 μm
Laser Operating Distance: 12 m
Process Temperature, Max: 1370 °C
Process Temperature, Min: -18 °C
Operating Temperature, Max: 50 °C
Operating Temperature, Min: 0 °C
