Shock: 50 g, 11 ms half-sine
Weight: 200 g
Accuracy: ± 0.08 %
Bandwidth: DC to 1 kHz
Stability: ± 0.1%
Vibration: 5-2000-5 Hz, 30 minute cycle,Curve L, Mil-Spec 810 figure 514-2-2, vertical and horizontal axis
Cable Length: 2 m
Current Draw: 10 mA
Accuracy Note: 0.08% BSL linearity, hysteresis and repeatability combined Thermal Accuracy: ± 0.50%(Span &Zero)
Output Signal: Voltage
Pressure Type: Differential
Pressure, Max: 5 psi
Pressure, Min: 0 psi
Response Time: <1 ms
Accuracy Class: < 0.1%
Proof Pressure: 4x Full Scale up to 1000 psi
Stability Note: Long Term Stability (1-Year): ± 0.1% FS typical
Supply Voltage: 10 to 30 Vdc
Pressure Cycles: 1 million, minimum
Electrical Output: 0 to 5 V
Materials, Wetted: 316L Stainless Steel
Output Resistance: 2500 Ω
Supply Power Note: Max Current Output: 2 mA
Zero/Balance Error: ± 0.5%
Media Compatibility: Air, Alkaline solutions, Any, Argon, Carbon dioxide, Dilute Acids, Gases, Helium, Hydraulic Oil, Hydrogen, Light Oil, Liquids, Nitrogen, Non-corrosive Dry Gasses, Oil, Oxygen, Solvents, Steam, Water, Water-based fluids
Proof Pressure Note: 4 times range
Line/Static Pressure: 500 psi max
Additional Features 1: Wet/Wet Diff 1/2" Conduit
Electrical Connection: 1/2 NPT male Conduit with Cable
Insulation Resistance: 100 MΩ
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Zero/Balance Error Note: ± 0.5% typical (1% maximum)
Operating Temperature, Max: 121 °C
Operating Temperature, Min: -45 °C
Compensated Temperature, Max: 85 °C
Compensated Temperature, Min: -17 °C
Span Setting Adjustable Range: ± 0.5% typical (1% maximum)
Positive Side differential wetted materials: 316L stainless steel
Negative Side differentional compatable fluids or gasses: Same as positive side
