Weight: 600 g
Frequency: 40 to 63 Hz
Form factor: 45 mm DIN Rail
Power Cycle: Turn-On Time: 20 ms; Turn-Off Time: 30 ms
Current, Min: 100 mArms
Voltage, Max: 1100 V
Control Output: SCR
Current Output: 45 A
Voltage Output: 48 to 600 Vac
Dropout Voltage: 10 Vac
Leakage Current: 250 µArms
Wire Gauge Note: Input Strandard Wire Gauge: 24 to 16 AWG; Input Solid Wire Gauge: 24 to 16 AWG; Output Stranded Wire Gauge: 16 to 8 AWG; Output Solid Wire Gauge: 16 to 10 AWG
Housing Material: UL 940VD (self-extinguishing)
Input Resistance: Current Regulated
Number of Phases: 1
Signal fail-safe: 500 Vµs
Thermal Sensitivity: 2600
Input Control Signal: 90 to 140 Vac
Leakage Current Note: Off-State Leakage µArms (@ Max Line Voltage and Ta = 25ºC)@ 48 to 600 Vac
Surge Current Rating: 1 Cycle, Max: 800 A; 1 s, Max: 160 A
Operating Voltage, Min: 1.35 V
Isolated Analog Voltage: 4000 Vrms
Measurement Current, Max: 6 mA
Measurement Current, Min: 5 mA
Storage Temperature, Max: 100 °C
Storage Temperature, Min: -40 °C
Input-to-Output Capacitance: 8 pF
Input/Output-to-Ground Isolation: 4000 Vrms
