Insulation: PVC/PE
Wire Gauge: 24 to 16 AWG
Cover Width: 2.2 mm
Thread Type: Metric
Amperage, Max: 0 A
Color Options: Gray
Terminal Width: 5.2 mm
Voltage Rating: N/A
Load Current, Max: 17.5 A
Tightening Torque: 0.6 to 0.8 Nm
Cross-Section Area: 1.5 mm²
V/A/AWG Compliance: Voltage Rating (UL-cUL IDC Connection)=600 V;Voltage Rating (UL-cUL Screw Connection)=600 V;Voltage Rating (IEC IDC Connection)=800 V;Voltage Rating (IEC Screw Connection)=800 V;Voltage Rating (UL-cUL Ratings)=600 V;Voltage Rating Connection Data=800 V;Amperage, Max (UL-cUL Ratings)=0.4167 A;Amperage, Max (IEC Screw Connection)=17.5 A;Amperage, Max (IEC IDC Connection)=17.5 A;Amperage, Max (UL-cUL Screw Connection)=0.4167 A;Amperage, Max (UL-cUL IDC Connection)=0.4167 A;Wire Gauge (UL-cUL Ratings)=24 to 16 AWG;Wire Gauge Connection Data=24 to 16 AWG;Wire Gauge (IEC Screw Connection)=26 to 12 AWG;Wire Gauge (IEC IDC Connection)=24 to 12 AWG;Wire Gauge (UL-cUL Screw Connection)=26 to 10 AWG;Wire Gauge (UL-cUL IDC Connection)=16 to 24 AWG;Amperage, Max (Connection Data) = 17.5 A
Contamination Class: 3
Number of Terminals: 2
Rated Surge Voltage: 8 kV
Additional Features 1: IDC hybrid TB
Electrical Connection: Hybrid Terminal Block
Compatible Wiring Note: Stranded with Ferrule=0.25 - 2.5 mm²;Stranded with Ferrule without Plastic Sleeve=0.25 - 1.5 mm²;Stranded with Twin Ferrule with Plastic Sleeve=0.5 - 1.5 mm²;Single/Multiple/Superfine Strand=1.5 mm²;Fine Stranded/Superfine Strand=24 - 16 AWG;Stranded with Ferrule with Plastic Sleeve=0.25 to 2.5 mm²;Solid=0.14 - 1.5 mm²;Halogen-Free=1.5 mm²
Insulation Strip Length: 9 mm
