Fall Time: 78 us
Rise Time: 35 us
Technology: Si
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Dual
Mounting Style: SMD/SMT
Transistor Type: 2 N-Channel
Qg - Gate Charge: 43 nC
Number of Channels: 2 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 2.5 W
Vgs - Gate-Source Voltage: - 12 V, + 12 V
Typical Turn-On Delay Time: 13 us
Typical Turn-Off Delay Time: 185 us
Id - Continuous Drain Current: 25 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 3.55 mOhms
Vds - Drain-Source Breakdown Voltage: 22 V
Vgs th - Gate-Source Threshold Voltage: 1.3 V
