Gain V/V: 100 V/mV
Shutdown: No Shutdown
Topology: Single
Input Type: Differential
Unit Weight: 37 mg
Amplifier Type: General Purpose Amplifier
Mounting Style: SMD/SMT
SR - Slew Rate: 400 mV/us
THD plus Noise: 0.02 %
Number of Channels: 1 Channel
Supply Voltage - Max: 32 V, +/- 16 V
Supply Voltage - Min: 3 V, +/- 1.5 V
Ib - Input Bias Current: 10 nA
Operating Supply Current: 10 mA
Vcm - Common Mode Voltage: 0 V to 30.5 V
Ios - Input Offset Current: 1 nA
Output Current per Channel: 40 mA
Vos - Input Offset Voltage: 300 uV
Maximum Dual Supply Voltage: +/- 16 V
Minimum Dual Supply Voltage: +/- 1.5 V
GBP - Gain Bandwidth Product: 750 kHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 40 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 85 dB
PSRR - Power Supply Rejection Ratio: 100 dB
