Shutdown: No Shutdown
Input Type: Rail-to-Rail
Output Type: Rail-to-Rail
Amplifier Type: Zero-Drift
Mounting Style: SMD/SMT
SR - Slew Rate: 150 mV/us
Number of Channels: 1 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.8 V
Ib - Input Bias Current: 200 pA
Operating Supply Current: 17 uA
Ios - Input Offset Current: 400 pA
Output Current per Channel: 11 mA
Vos - Input Offset Voltage: 10 uV
GBP - Gain Bandwidth Product: 350 kHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 350 fA/sqrt Hz
en - Input Voltage Noise Density: 62 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 123 dB
PSRR - Power Supply Rejection Ratio: 130 dB
