Frequency:
+ Frequency Range: 9 kHz to 7.500000000 GHz
+ Frequency Resolution: 1 Hz
Frequency Span:
+ Span Range: 0 Hz, 100 Hz to max frequency of instrument
+ Span Uncertainty: ± span / (sweep points-1)
SSB Phase Noise(20℃ to 30℃,fc=1 GHz):
+ Carrier Offset:
10 kHz: < -106 dBc/Hz
100 kHz: < -104 dBc/Hz
1 MHz: < -115 dBc/Hz
Bandwidth:
+ Resolution Bandwidth（-3 dB）: 1 Hz to 1 MHz, in 1-3-5-10 sequence
+ RBW Accuracy: < 5% nominal
+ Resolution Filter Shape Factor (60 dB : 3 dB): <5 nominal
+ Video Bandwidth (-3 dB): 10 Hz to 3 MHz, in 1-3-5-10 sequence
+ Resolution Bandwidth（-6 dB）(EMI): 200 Hz，9 kHz，120 kHz，1 MHz
Amplitude:
+ Measurement range:
DANL to +10 dBm,100 kHz to 10 MHz, Preamp Off
DANL to +20 dBm,10 MHz to 7.5 GHz, Preamp Off
+ Max Input Level
+ DC Voltage: 50 V
+ Continuous RF power: Attenuation = 40 dB, +20 dBm(100mV)
+ Max. damage level: +30 dBm（1 W）
Display:
+ Type: TFT LCD
+ Resolution: 1024*768
+ Size: 10.4 inches
+ Color: 65536
Appearance:
+ Dimensions: 375 mm (W) × 185 mm (H) × 120 mm (D)
+ Weight: Approx. 5.0 kg (without package)
