- Rated Power (VA): 2000
- Coupling Mode: Direct
- Form: 1Ø/2Ø
- Output Voltage Max (1Ø/2Ø) (l-n/l-l): 150/300
- Current (1Ø/2Ø) (Arms): 20/14
- Frequency Range: 15~1200
- Input Power: 1Ø
- Unit Height (In/mm/U): 5.25/133/3U
- Unit Weight (Lbs/Kg): 75 /34
- Output Frequency:
15~1200 Hz Direct Coupled
- Line Regulation: 0.1% max for a ±10% line change
- Load Regulation:
Direct Coupled:
0.25% 15 to 400 Hz.,
0.50% 400 to 1,200 Hz.
Improves to <0.1% with external sense and CSC enabled
- Output Distortion:
0.25% THDAVG 15~200 Hz
1.25% THDAVG 200~1200 Hz
- Ripple and Noise: -66dB
- Response Time: 60 μsec typical
