Color: Blue
Width: 10.3 mm
Height: 48.3 mm
Length: 68 mm
Unit Weight: 21.394 g
REACH - SVHC: Details
Current Rating: 55 A
Mounting Style: DIN Rail (NS 35/7.5, NS 35/15)
Voltage Rating: 800 V
Wire Gauge Max: 6 AWG
Wire Gauge Min: 20 AWG
Housing Material: Polyamide (PA)
Wire Gauge Range: 20 AWG to 6 AWG
Connection Method: Screw
Flammability Rating: UL 94 V-0
Number of Positions: 5 Position
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 60 C
