Color: Gray
Pitch: 29 mm
Width: 29 mm
Height: 66 mm
Length: 184 mm
Unit Weight: 184.280 g
Current Rating: 192 A
Mounting Style: DIN Rail (NS 35/7.5, NS 35/15)
Voltage Rating: 1.5 kV
Wire Gauge Max: 2/0 AWG
Wire Gauge Min: 8 AWG
Wire Gauge Range: 8 AWG to 2/0 AWG
Connection Method: Bolt, Screw
Flammability Rating: UL 94 V-0
Number of Positions: 1 Position
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 60 C
