Sensor: UFPA
Temperature range: -10°C-400°C
Measurement resolution: 0.1 °C
Mode: Auto gain
Accuracy: ±2.0°C or ±2%
Measuring distance: 25cm
Response time: 500ms (95% of reading)
Emissivity: 0.01-0.99 adjustable (default: 0.95)
IR resolution: 19,200 pixels (160 x 120)
Pixel size: 17|jm
Color palette: Iron red, rainbow, grayscale, red-white,
Wavelength range: 8um - 14um
Field of view (FOV): 56° (H) x 42° (V)
Spatial resolution (IFOV): 11mrad
Thermal sensitivity (NETD): <50mK
Frame rate: <9Hz
Image format: BMP
General parameters
PC software: Yes
Data transmission: Type-C USB interface
Product size (LxWxH): 236mm x 75.5mm x 86mm
Display type: 2.8" TFT LCD
Display resolution: 320 x 240 pixels
Battery: 3.7 V/5000mAh rechargeable Li-ion battery
Auto power off: 5 minutes, 10 minutes, 30 minutes, off (default: 30 minutes)
Battery life: 36 hours
Charging time: 14 hours
Charging voltage/current: 5V/2A
Image storage: Micro SD card
Drop test: 2m
IP rating: IP65
Certification: CE
Storage temperature: -20°C~60°C (-4°F~140°F)
Operating temperature: 0°C-50°C (32°F-122°F)
Operating humidity: <90%RH (non-condensing)
Altitude: W2000m
Standard accessories: User manual, USB cable, 16GB Micro SD card
