Capacity: 15kVA
AC INPUT
Phase: 3Ø3W+G ( ∆)/ 3Ø4W+G ( Y ) (Option)
Voltage*1: 220V/ 380 V
Voltage Range: -13% ~ +17%/ -22%~ +30% (Option)
Frequency: 47Hz-63Hz
AC OUTPUT
Phase: 3Ø3W+G ( ∆)/ 3Ø4W+G ( Y ) (Option)
Voltage*2: 220V/ 380 V/ 230V/ 400V / 240V / 415V (Option)
Accuracy: ±2% ( ±2% ~ ±5% adjustable)
Frequency: 47Hz-63Hz
Power Factor: ±0.7-1
METER & INDICATOR
VoltMeter: LED digital meter for voltage of each phase, Accuracy ≤ 1%
Ammeter: LED digital meter for voltage of each phase, Accuracy ≤ 1%
Error: Error code and message available when a abnormal condition occurs
LED Indicator: Normal, abnormal, over voltage, under voltage, over load, auto/manual mode
PROTECTION
Over/ Under Voltage: Sound- light alarm with output shutdown
Missing Phase: Sound- light alarm with output shutdown
Incorrect Phase Sequence: Sound- light alarm with output shutdown
Bypass Swtich: Manual Bypass Swtich (Option)
Over Load: Sound - light alarm
GENERAL
Efficiency : ≥ 97% at Full Load
Voltage Modulation: ≥ 4V/S
Total Harmonic Distortion : ≤ 1% (Additional distortion)
HMI: LED display for meter and auto/manual voltage adjustment
Audible Noise(1 meter): ≤ 55dB
Cooling System: Fan Cooling
Connections: Terminal
ENVIRONMENT
Operational Temperature: -5°C ~ 40°C
Humidity : <95% Non-condensing
Altitude: 1000m
Dimension(H x W x D): 750 x 400 x 550mm/ 29.52 x 15.74 x 21.65 inch
Weight: 160kg/ 352.7 lbs
*1 Please contact for other voltage specification.
*2 The rated input voltage is 380V.
* All specifications are subject to change without notice.
