Power: 150Wx2
Current: 0~30A; 0~30A
Voltage: 0~80V; 0~80V
Min.Operation Voltage: 1V at 30A; 1V at 30A
-CC mode
+Range: 3A/30A; 3A/30A
+Resolution: 0.05/0.5mA
+Accuracy: 0.1% + 0.1% F.S.
-CR mode
+Range: 0.0443~2.66~159.6KΩ
+Resolution: 16 bits
+Accuracy: 0.2%
-CV mode
+Range: 6V/80V
+Resoluton: 0.135mV/1.35mV
+Accuracy: 0.05% + 0.05% F.S.
-CP mode
+Range: 15W/150W
+Resolution: 0.25mW / 2.5mW
+Accuracy: 0.5% + 0.5% F.S.
- Option (necessary) : 3302F- single channel mainframe ; 3305F- two channels mainframe ; 3300F- four channels mainframe
- Optional interface : GPIB, RS232, USB, LAN
