Gain: 4 dBi, 5 dBi, 4.5 dBi, 5 dBi
VSWR: 1.5, 1.4
Style: Dome
Width: 64.48 mm
Height: 76 mm
Length: 51.85 mm
IP Rating: IP67
Impedance: 50 Ohms
Cable Type: 17 ft RG58, RG174
Application: Telematics, Location Base Services, First Responders, Government, Energy Vehicles, Fleet Management, Railroad
Unit Weight: 1.54 kg
Mounting Style: Direct / Permanent Mount
Electrical Type: Active
Number of Bands: 9 Band
Center Frequency: 830 MHz, 1.9325 GHz, 2.45 GHz, 2.5 GHz, 3.25 GHz
Mechanical Style: Module
Maximum Frequency: 5.925 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: SMA Male, RP-SMA Male
Protocol - GPS, GLONASS: GLONASS, GPS
Protocol - WiFi - 802.11: 802.11, WiFi, WiMAX, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM, UMTS
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
