Press capacity (Ton): 25
Rated tonnage point (mm): 3.2
Slide strokes per minute (S.P.M): 60~140
Slide stroke length (mm): 60
Max die height mm): 200
Slide adjustment amount (mm): 50
Slide size (mm): 470*230*50
Bolster size(mm): 680*300*70
Slide center to machine distance (mm): 155
Platform to floor distance (mm): 795
Shank hole (mm): Φ38.1
Main motor power (KW*P): 3.7*4
slide adjust device: /
Air pressure (kg*cm²): 6
Press accuracy grade(Grade): JIS 1
Press dimension(L*W*H)mm: 1280*850*2200
Press weight (Tons): 2.1
Die cushion capacity(Ton):/
Die cushion stroke (mm):/
Die cushion active area (mm²):/
