Gain: 16 dB
Technology: GaAs
Unit Weight: 2.861 g
Mounting Style: SMD/SMT
Test Frequency: 10 GHz
Input Return Loss: 10 dB
NF - Noise Figure: 5.5 dB
Number of Channels: 1 Channel
Operating Frequency: 0 Hz to 26.5 GHz
Supply Voltage - Max: 7 V
Supply Voltage - Min: 4 V
Pd - Power Dissipation: 495 mW
Operating Supply Current: 74 mA
Operating Supply Voltage: 4 V to 7 V
P1dB - Compression Point: 18 dBm
OIP3 - Third Order Intercept: 29 dBm
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
