Quectel BG600LM3AA-D08-TA0AA EGPRS, GNSS, LTE CatM1, LTE Cat NB2 Embedded, 0-6000, Cable assembly, 150mm, -, SMA-female to IPEX MHFI

Core: ARM Cortex M7

Data Rate: 588 kb/s, 1.119 Mb/s

Frequency: 850 MHz, 900 MHz, 1.8 GHz, 1.9 GHz

Dimensions: 18.7 mm x 16 mm x 2.1 mm

Output Power: 21 dBm

Interface Type: ADC, GPIO, I2C, PCM, UART, USB 2.0

Supply Voltage - Max: 4.3 V

Supply Voltage - Min: 3.3 V

Antenna Connector Type: Built-In

Protocol - GPS, GLONASS: GNSS

Operating Supply Voltage: 3.8 V

Supply Current Receiving: 186 mA, 148 mA

Maximum Operating Temperature: + 75 C

Minimum Operating Temperature: - 35 C

Protocol - Cellular, NBIoT, LTE: EGPRS, LTE Cat-M1, LTE Cat NB2
