Thermal Imaging Parameters
Detector: Uncooled VOx detector
Infrared Resolution: 1280×1024
Pixel pitch: 12μm
Spectral Band: 8μm~14μm
Thermal Sensitivity (NETD): <50mK
Temperature Measurement Function
Measurement Range: -20℃~+150℃,0℃~550℃
Measurement Accuracy: ±2°C or ±2% of readings, whichever is greater.
Temperature Measurement Correction: Reflected temperature, ambient temperature, atmospheric transmissivity, object emissivity, distance
Measurement Tool: Settings of measurement rules for a total of 12 points, lines, and areas Supports isotherm setting
Temperature Width Stretch: Support temperature width stretch
Image and Video
Frame Rate: 15Hz
Palettes: 18 color palettes including black-hot, white-hot, iron red, rainbow, etc.
Thermal Image Capture: Support thermal image capture and secondary analysis
Mirror Image: Horizontal/Vertical/Diagonal
Digital Zoom: 1.0~8.0 continuous zoom (step size: 0.1)
System Interface
Communication interface: RJ45, supporting Gigabit network.
Network Protocol: TCP, UDP, ICMP, DHCP
Interface Protocol: GigE Vision
Device Specifications
Operating Temperature: -20℃~+60℃
Power supply mode: 6~16V DC
Typical Power Consumption: 4.5W
Dimensions: 70mm×63mm×143mm (19mm lens)
Weight: Approx. 725g (19mm lens)
