Detector Type: Uncooled infrared detector
Infrared Resolution: 256×192
Pixel Size: 12μm
Spectral Band: 7.5-14μm
Thermal Sensitivity (NETD): ＜40mK (25°C,F1.0)
Frame Rate: 25Hz
Lens Focal Length: 3.2mm
FOV: 56°×42°
Spatial Resolution (IFOV): 3.75mrad
Focusing Mode: Fixed focus
Minimum Imaging Distance: 0.3m
Measurement Range: -20°C ~ +150°C, 100°C ~ +400°C
Measurement Accuracy: ±2°C or ±2% of readings, whichever is greater
Imaging Display
Display: 2.8 inch, 320×240
Digital Zoom: 1× 2× 4×
Palettes: 4 options
Image Mode: Infrared
Temperature Width Stretch: Auto
Measurement and Analysis
Analysis Functions on the Device: Central temperature point/Highest temperature point/Lowest temperature point
Supporting Software: PC (Infrared Analysis Software)
Image Storage
Storage Medium: Standard 32GB MicroSD, up to 128G
System Functions
Alarm Type: Highest/Lowest temperature alarm in full frame; Image pop-ups, flash prompts; Auto image capture at alarm time (with temperature data).
Power Management: Auto shut-down setting
Others
Battery: Built-in rechargeable lithium-ion battery
Charging Mode: USB Type-C
Battery Life: About 9h
Interface: USB Type-C, SD card
Tripod Socket: UNC 1/4-20 interface for tripod
Operating Temperature: -10°C~+50°C
Operating Humidity: 10%~95% (non-condensing)
Storage Temperature: -20°C~+60°C
Ingress Protection Rating: IP54
Shock and Vibration
Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6)
Weight and Dimensions: About 520g, 237×75×92mm
Authentication: CE/RoHS/CMA, etc.
Packing List: Infrared camera×1, USB cable, 32GB SD card, user manual, storage bag, certificate of qualification, calibration certificate
