Thermal Imaging
Infrared Resolution: 160×120
Super Resolution: 320×240
Spectral Band: 8-14μm
NETD: 40mK
Frame Rate: 25 Hz
Lens Focal Length: 2.6mm
FOV: 40°×30°
IFOV: 4.62 mrad
Focusing Mode: Fixed focus
Minimum Imaging Distance: 11cm
Measurement Range: -20~150℃; 100~550℃; auto switching
Imaging Display
Display: 2.8-inch; 240×320 resolution
Palettes: 6 options
Image Mode: Infrared
Temperature Width Stretch: Automatic/Manual
Image Storage
Storage Medium: 8GB Internal Memory
Image File Format: JPEG
Video Recording and Transmission
Communication Interface: USB2.0
Video Recording: Standard MP4 video recording
Video Resolution: 240×320
Video Transmission: UVC (with temperature data)
Measurement and Analysis
Measurement Accuracy: ±2°C or ±2% of readings (whichever is greater)
Measurement Unit: Celsius degree, Fahrenheit degree, Kelvin
Temperature Alarm: Supports (high and low temperature alarms)
Automatic lmage Capture Upon Alarm: Supports (with temperature data)
Color Alarm (lsotherm): Above / Below / Between — The image within the isotherm range is displayed in pseudo color, while other areas are shown in white-hot mode
Analysis Functions on the Device: Central point / Highest temperature point / Lowest temperature point / 3 custom points
Analysis Report: PDF forma(requiring support from PC analysis software)
Supporting Software: PC (Infrared Analysis Software)
System Functions
Connection Mode: USB2.0 Type-C
Laser Pointer: Not support
Quick Start: support
WiFi: Not support
Others
Battery: 2750mAh lithium-ion battery
Charging Time: Above 90% within 75 minutes
Charging Mode: USB2.0; Type-C cable charging; Not support fast charging
Battery Life: ≥10 hours
Tripod Socket: Support
Operating Temperature: -20°C~ 50°C
Storage Temperature: -40°C~ 70°C
Extemal Interface: Type-C USB2.0 Tripod socket
Ingress Protection Rating: IP54
Shock and Vibration
shock: 25G (IEC60068-2-27); vibration: 2.5G (IEC60068-2-6); 2-meter drop
Weight and Dimensions: 257g±10g (including battery), 206.9×67×81.5mm
