Thermal Module
Detector Type: VOx, uncooled FPA detectors
Spectral Range: 8~14μm
NETD: ≤40mK(@25°C,F#1.0,25Hz)
Resolution: 256×192
Pixel Pitch: 12μm
Focal Length: 3.2mm/7mm
Optical Module
Sensor: 5MP 1/2.7" Progressive Scan CMOS
Resolution: 2560×1920
Focal Length: 4mm/8mm
IR distance: 30m
Image Function
Bi-Spectrum Image Fusion: Support
Temperature Measurement
Temperature Range: -20℃~+550℃
Temperature Accuracy: ±2℃ or ±2%
Temperature Measurement: Suport 4 temperature measure ment rules(fullframe, point, line, area)
Smart Function
Fire Detection: Support
VCA: Support Line Crossing&Intrusion detection with AI human/Vehicle recognition
2-Way Audio: Support
Linkage Action: Video/ Snapshot/Email/Alarm output/sound and light alarm
System Interface
Power: DC 12V±25%/POE(802.3af)
Network: 1 RJ45 10M / 100M self-adaptive Ethernet port
Audio: 1 in/1 out
Alarm: 2 in/1 out
Storage: Micro SD memory（maximum 256G）
Reset: Support
Serial Port: 1 channel RS485, can support Pelco protocol
General
Work Environment: -40℃~+70℃；<95%RH
Protection: IP66
Power Consumption: ≤5W
Dimenstion(mm): Φ129×96
Weight: ≤0.8kg
