Thermal Module
Detector Type: VOx, uncooled FPA detectors
Spectral Range: 8~14μm
NETD: ≤40mK(@25°C,F#1.0,25Hz)
Resolution: 640×512
Pixel Pitch: 12μm
Focal Length: 9.1mm/13mm/19mm/25mm
Temperature Measurement
Temperature Range: -20℃~+550℃
Temperature Accuracy: ±2℃ or ±2%
Temperature Measurement: Support 4 temperature measurement rules (fullframe, point, line, area)
Smart Function
Fire Detection: Support
VCA: Support Line Crossing & Intrusion detection
2-Way Audio: Support
Linkage Action: Video/ Snapshot/Email/Alarm output/sound and light alarm
System Interface
Power: DC 12V±25%/POE(802.3at)
Network: 1 RJ45 10M / 100M self-adaptive Ethernet port
Audio: 1 in/1 out
Alarm: 2 in/1 out
Storage: Micro SD memory（maximum 256G）
Reset: Support
Serial Port: 1 channel RS485, can support Pelco protocol
General
Work Environment: -40℃~+70℃；<95%RH
Protection: IP66
Power Consumption: ≤4W
Dimenstion(mm): 319.5×121.5×103.6
Weight: ≤1.5kg
