Thermal Module
Detector Type: VOx, uncooled FPA detectors
Spectral Range: 8~14μm
NETD: ≤40mK(@25°C,F#1.0,25Hz)
Resolution: 640×512
Pixel Pitch: 12μm
Focal Length: 9.1mm/13mm/19mm/25mm/35mm Athermalized/Motorized lens
Optical Module
Sensor: 4MP 1/1.8" Progressive Scan CMOS
Resolution: 2688×1520
Focal Length: 6.5~130mm, 20x
Image Function
Picture in Picture: Support
PTZ
Pan: 360° continuous，0.1°~100°/s
Tilt: -90°~+90°，0.1°~60°/s
Preset: 256
Scan mode: Preset/Pattern Scan/Patrol Scan/ Linear Scan/Panorama Scan
Wiper: wiper
Temperature Measurement
Temperature Range: -20℃~+550℃
Temperature Accuracy: ±2℃ or ±2%
Temperature Measurement: Suport 4 temperature measure ment rules(fullframe, point, line, area)
Smart Function
Fire Detection: Support
VCA: Support Line Crossing&Intrusion detection
2-Way Audio: Support
Linkage Action: Video/ Snapshot/Email/Alarm output/sound and light alarm
System Interface
Power: DC 12V±25%
Network: 1 RJ45 10M / 100M self-adaptive Ethernet port
Audio: 1 in/1 out
Alarm: 2 in/2 out
Storage: Micro SD memory（maximum 256G）
Reset: Support
Serial Port: 1 channel RS485, can support Pelco protocol
General
Wor Environment: -40℃~+70℃；<90%RH
Protection: IP66
Power Consumption: max. 30w
Dimenstion(mm): 358×166×203
Weight: ≤5kg
