Thermal Module
Detector Type: VOx, uncooled FPA detectors
Spectral Range: 8~14μm
NETD: ≤40mK(@25°C,F#1.0,25Hz)
Resolution: 640x512
Pixel Pitch: 12μm
Focal Length: 9.1mm/13mm/25mm/50mm Athermalized/Motorized lens
Optical Module
Sensor: 4MP 1/1.8" Progressive Scan CMOS
Resolution: 2560×1920
Focal Length: 6.5~240mm, 37x
IR distance: 200m
Image Function
Bi-Spectrum Image Fusion: Support
PTZ
Pan: 360° continuous，0.1°~200°/s
Tilt: -27°~+90°，0.1°~120°/s
Preset: 1024
Scan mode: Preset/Pattern Scan/Patrol Scan/ Linear Scan/Panorama Scan
Wiper: auto-wiper
Temperature Measurement
Temperature Range: -20℃~+550℃
Temperature Accuracy: ±2℃ or ±2%
Temperature Measurement: Suport 4 temperature measure ment rules(fullframe, point, line, area)
Smart Function
Fire Detection: Support
VCA: Support Line Crossing&Intrusion detection with AI human/Vehicle recognition
2-Way Audio: Support
Linkage Action: Video/ Snapshot/Email/Alarm output
System Interface
Power: DC 24V±25%
Network: 1 RJ45 10M / 100M self-adaptive Ethernet port
Audio: 1 in/1 out
Alarm: 7 in/2 out
Storage: Micro SD memory（maximum 256G）
Reset: Support
Serial Port: 1 channel RS485, can support Pelco protocol
General
Work Environment: -40℃~+70℃；<95%RH
Protection: IP66
Power Consumption: ≤8W
Dimenstion(mm): Φ250×413
Weight: ≤8kg
