Detector Type: Uncooled infrared detector
Infrared Resolution: 1280 x 1024
Pixel Size: 12μm
Super Resolution: 2560 x 2048
Spectral Band: 7.5-14μm
Thermal Sensitivity (NETD): ＜25mK (25°C,F1.0)
Frame Rate: 30Hz
Lens Focal Length: Standard lens: 34.9mm; wide-angle lens: 19.8mm; telephoto lens: 72.9mm; macro lens (0.2×): 17.8mm; super macro lens (0.4×): 15.2mm
FOV: Standard lens: 25°×20°; telephoto lens: 12°×9.6°; wide-angle lens: 45°×36°
Spatial Resolution (IFOV): Standard lens: 0.34mrad; telephoto lens: 0.17mrad; wide-angle lens: 0.6mrad; macro lens: One pixel corresponds to 50μm; super macro lens: One pixel corresponds to 25μm.
Focusing Mode: Manual focus,electri micro focus, one-button center focus, automatic center focus,single-touch automatic focus, laser-assisted focus
Minimum Imaging Distance: Standard lens: 0.5m; telephoto lens: 2.3m; wide-angle lens: 0.2m; macro lens: 46mm; super macro lens: 13mm
Measurement Range: Standard: -20°C~+150°C (low temperature range), 150°C~800°C (medium temperature range). Optional: 400°C~1500°C, other ranges (high temperature range)
Imaging Display
Display: 5.5-inch LCD touch screen, resolution 1920×1080
Visible light camera: 13 megapixels
Digital Zoom: 1–15 times, continuously adjustable roller
Palettes: 19 options
Image Mode: Infrared, visible light, PIP, dual-spectrum fusion
Temperature Width Stretch: support
Measurement and Analysis
Laser Rangefinding: Support
Area Measurement: Support
Position: Support
Temperature Difference Analysis: Support
Trend Analysis: Supports temperature trend recording and analysis.
Image Freezing: Support
Analysis Report: PDF format. Support editing and template importing on the PC client.
Supporting Software: PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP)
Image Storage
Standard 64GB MicroSD. Support SD, SDHC, and SDXC, up to 2TB.
Text Notes: support
Voice Annotation: support
Video Functions
Radiation Infrared Video Recording: Support compressed full radiation video recording (.irv), up to 15Hz video recording
Non-radiation Infrared or Visible Light Video Recording: Standard MP4 video recording
Radiation Infrared Video Stream Transmission: Analysis at about 25Hz on PC
Non-radiation Infrared Video Stream Transmission: RTSP H.264
Video Resolution: 1920×1080
System Functions
Ổn định hình ảnh thông minh: Hỗ trợ
Ghép ảnh toàn cảnh thông minh: Hỗ trợ
Kiểm tra định kỳ thông minh: Hỗ trợ. Nhập và chỉnh sửa gói tác vụ chung, đặt tên hình ảnh tiêu chuẩn và tự động
Ghi lại tự kiểm tra trong kiểm tra định kỳ: Hỗ trợ
Ghi hình video hai phổ: Quay đồng thời video hồng ngoại và video ánh sáng nhìn thấy, ở định dạng MP4
Giao thức truyền thông: Wi-Fi, Bluetooth, USB
Điều khiển bằng giọng nói: Trợ lý giọng nói, nhận diện lệnh nhanh
Flashlight: Hỗ trợ
Others
Microphone/Speaker: support
Battery: 9000mAh lithium-ion battery, field-replaceable, fast charging
Charging Mode: USB Type-C or desktop charger
Battery Life: Continuous operating time ≥ 3 hours (depending on the actual environment and service conditions)
Interface: USB3.0 Type-C, SD card, SIM card, Mini HDMI
Tripod Socket: UNC 1/4-20 interface for tripod
Operating Temperature: -15°C~+50°C
Operating Humidity: 10%~95% (non-condensing)
Storage Temperature: -40°C~+70°C
Ingress Protection Rating: IP54
Shock and Vibration
Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6)
Weight and Dimensions: <1.7kg (with battery), 140×210×115mm
