Width: 22.2 mm
Height: 17.75 mm
Length: 33.7 mm
Industry: Industrial
Approvals: EN60950-1, UL60950-1
Compliance: CAN/CSA; EAC; ERP; IEC; RoHS
Dimensions: 33.7 mm x 22.2 mm x 17.75 mm
Efficiency: 68%
Unit Weight: 25 g
Output Power: 1 W
Input Voltage: 80 VAC to 277 VAC
Mounting Style: Through Hole
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kV
Number of Outputs: 1 Output
Input Voltage - Max: 264 VAC
Input Voltage - Min: 80 VAC
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 200 mA
Output Voltage-Channel 1: 5 VDC
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 25 C
