Width: 6 mm (0.236 in)
Height: 10.2 mm (0.402 in)
Length: 19.6 mm (0.772 in)
Industry: Medical
Compliance: ANSI; CB; CSA; EAC; IEC; REACH; RoHS; UL
Efficiency: 77%
Unit Weight: 2.600 g
Output Power: 1 W
Input Voltage: 13.5 V to 16.5 V
Mounting Style: Through Hole
Isolation Voltage: 5.2 kV
Number of Outputs: 1 Output
Input Voltage - Max: 16.5 V
Input Voltage - Min: 13.5 V
Input Voltage, Nominal: 15 V
Output Current-Channel 1: 303 mA
Output Voltage-Channel 1: 3.3 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
