Width: 25.4 mm (1 in)
Height: 10.2 mm (0.402 in)
Length: 40.6 mm (1.598 in)
Industry: Medical, Industrial
Compliance: ANSI; CB; CSA; EAC; IEC; REACH; RoHS; UL
Efficiency: 88%
Unit Weight: 24 g
Output Power: 20 W
Input Voltage: 9 V to 36 V
Mounting Style: Through Hole
Isolation Voltage: 5 kV
Number of Outputs: 1 Output
Input Voltage - Max: 36 V
Input Voltage - Min: 9 V
Input Voltage, Nominal: 24 V
Standard Packaging Size: 290 mm x 43.5 mm 19.7 mm
Output Current-Channel 1: 833 mA
Output Voltage-Channel 1: 24 V
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
