Width: 7.5 mm (0.295 in)
Height: 12.2 mm (0.48 in)
Length: 19.6 mm (0.772 in)
Industry: Industrial
Compliance: EAC; IEC; REACH; RoHS; UL
Efficiency: 84%
Unit Weight: 2.800 g
Output Power: 3 W
Input Voltage: 10.8 V to 13.2 V
Mounting Style: Through Hole
Isolation Voltage: 3 kV
Number of Outputs: 1 Output
Input Voltage - Max: 13.2 V
Input Voltage - Min: 10.8 V
Input Voltage, Nominal: 12 V
Output Current-Channel 1: 600 mA
Output Voltage-Channel 1: 5 V
Maximum Operating Temperature: + 90 C
Minimum Operating Temperature: - 40 C
