Electricity, flow: Set range: AC 3- -30Amps resolution: 0. lAmp / stepAccuracy: ± (2% set point + 0.02A)
Electricity, pressure: Range: AC 6V Maxo (open-circuit voltage)
Frequency, rate: 50 / 60Hz optional accuracy: ±I00PPM
Wave, shape: sinusoidal wave
ammeter: Measurement range: 3- -30A Resolution: 0. lA / stepAccuracy: ± (2% reading + 0. 1A)
ohmmeter: Measurement range: 0- -510mΩ, 0- -120m when the output current is 10A, and when the output current is 10- -30AResolution: lm Ω / stepAccuracy: ± (2% reading + l m Ω)
calculagraph: Timing range: 0- -999.9 seconds resolution: 0. lS / stepAccuracy: ± 50 ms
Offset mode: automatic or manual
Milliohmoffset: Maximum Offset range: 100 mΩ Max.
setting
Resolution: lm Ω / step
Accuracy: ± (2% Setpoint + M Q)
Determining value setting: Upper limit of resistance setting range: 0-510mQ resolution: lm Ω / step accuracy: ± (2% setting + lm)
Test time setting: Set range: 0. 5- -999.9 seconds resolution: 0. 1S / stepAccuracy: ± (0. 01% + 50m s)
