Width: mm
Height: mm
Length: mm
Fall Time: 20 us
Rise Time: 20 us
Output Type: NPN Phototransistor
Unit Weight: 255.296 mg
Mounting Style: Through Hole
Isolation Voltage: 5000 Vrms
Number of Channels: 1 Channel
If - Forward Current: 80 mA
Vf - Forward Voltage: 1.3 V
Vr - Reverse Voltage: 6 V
Current Transfer Ratio: 100 %
Pd - Power Dissipation: 150 mW
Maximum Collector Current: 30 mA
Current Transfer Ratio - Max: 400 %
Current Transfer Ratio - Min: 100 %
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 55 C
Maximum Collector Emitter Voltage: 40 V
Maximum Collector Emitter Saturation Voltage: 250 mV
