Voltage Range: 100V~500V
Voltage Accuracy: ± 0.03% F.S
Voltage Resolution: 1mV
Current Range: 100A/150A/200A/300A/400A/600A
Current Accuracy: ± 0.03% F.S
Current Resolution: 1mA
Current start response time: 3ms (10%~90% F.S)
Current switching time: 5ms (-90%~90% F.S)
Third-party device integration: Supports linkage of temperature box, MTV/MTS, and I/O control box
Cabinet size (W×D×H mm): 600×800×2000
ADVANTAGES
Support single battery voltage consistence test
Support multi-channel parallel
Power factor value up to 0.99
Anti-reverse connection and data protection
Battery discharge and energy feedback efficiency ≥92%
Modular design, easy for maintenance
Support RS485/CAN communication, baud rate is changeable
Support DBC import at one-click
Support user-defined BMS values as control/protection parameters
Support slope charging and discharging
User-defined login management rights are supported
Support four-quadrant charging and discharging function (optional)
High-speed working condition pulse test
Current-SOC matrix test
Battery capacity test
Static/dynamic SOC test
Cycle life test
Charging/discharging test
Temperature characteristic test
DCIR test
APPLICATIONS
Applied in the testing and quality control of lithium battery modules & packs such as new energy vehicles, energy storage base stations, and can realize the integration of charging and discharging data monitoring.
