Voltage Range: 60V
Voltage Accuracy: ± 0.05% F.S
Voltage Resolution: 1mV
Current Range: 20A/30A/40A/60A
Current Accuracy: ± 0.05% F.S
Current Resolution: 1mA
Current start response time: 10ms (10%~90% F.S)
Current switching time: 20ms (-90%~90% F.S)
Third-party device integration: Supports linkage of temperature box, MTV/MTS, and pressure sensor
Cabinet size (WDH mm): 600x850x1030 / 600x800x1980
ADVANTAGES
Support single battery voltage consistence test
Support multi-channel charge-discharge curve comparison
Support multi-channel parallel
Power factor value up to 0.99
Anti-reverse connection and data protection
Battery discharge and energy feedback efficiency ≥90%
Modular design, easy for maintenance
Support RS485/CAN communication, baud rate is changeable
Support DBC import at one-click
Support user-defined BMS values as control/protection parameters
BMS voltage and current following test
User-defined login management rights are supported
Cycle life test
Battery capacity test
CAN/RS485 communication test
Static/dynamic SOC test
Charging/discharging test
Temperature characteristic test
Overcharge/discharge test
DCIR test
APPLICATIONS
Applied in the testing and quality control of smart lithium batteries or battery packs such as e-bike, drones, medical equipment, balance-robot, and vacuum cleaner, and can realize the integration of charging and discharging data monitoring
