Pitch: 1.27 mm (0.05 in)
Application: Board-to-Board
Row Spacing: 1.27 mm (0.05 in)
Unit Weight: 61.500 mg
Housing Color: Black
Contact Gender: Pin (Male)
Current Rating: 3.4 A
Mounting Angle: Straight
Mounting Style: Through Hole
Number of Rows: 2 Row
Contact Plating: Gold
Contact Material: Phosphor Bronze
Housing Material: Liquid Crystal Polymer (LCP)
Termination Style: Solder Pin
Mating Post Length: 3.05 mm (0.12 in)
Flammability Rating: UL 94 V-0
Number of Positions: 10 Position
Termination Post Length: 2.29 mm (0.09 in)
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
