Width: 33.1 mm
Height: 67.7 mm
Length: 49.4 mm
Coil Type: Non-Latching
Unit Weight: 120 g
Coil Voltage: 24 VAC
Contact Form: DPST (2 Form A)
Mounting Style: Panel Mount
Coil Resistance: 275 Ohms
Coil Termination: Quick Connect
Contact Material: Silver Alloy (Ag)
Power Consumption: 1.9 W
Switching Voltage: 300 VAC
Relay Contact Form: 2 Form A (DPST-NO)
Contact Termination: Quick Connect
Contact Current Rating: 25 A
Maximum Switching Current: 100 mA
