Frequency Range (nominal): 1-2 GHz
Frequency Range (useable): 0.92 - 2.2 GHz
Gain: ≈ 20 dBi
Antenna Factor: 11...17 dB/m
VSWR: typ. < 1.5
Front to Back Ratio: typ. > 27 dB
Half Power Beamwidth (E-Plane): 16°
Half Power Beamwidth (H-Plane): 15°
6 dB Beamwidth (E-Plane): 22°
6 dB Beamwidth (H-Plane): 24°
Connector: 7/16
Max. Input Power:1.8 kW (1 GHz)/1.2 kW (2 GHz)
Mounting Threads: 3/8", 5/8"
Dimensions: 1.3 x 0.98 x 1.9 m
Weight: 27 kg
Material: Aluminium
