Frequency range: 150 kHz – 230 MHz
Type of cable: Coaxial, 50 Ω
Connector: BNC
Max. voltage line – ground: 150 V DC, 100 V AC
Max. line current/path: 1 A DC
Common mode impedance EuT–side:
150 kHz – 30 MHz: 150 Ω ± 20 Ω
30 MHz – 230 MHz: 100 Ω + 60 Ω / –45 Ω
Phase error: 0° ± 20°
Measuring port: 50 Ω BNC
Max. voltage measuring port: < 20 V AC
Voltage division factor EuT–measuring port:
150 kHz – 30 MHz: 9.5 dB ± 1 dB
30 MHz – 230 MHz: 9.5 dB +4 dB / –2 dB
3 dB transmission bandwidth EuT–AE: > 250 MHz
Dimensions (W × H × D): 225 mm × 129 mm × 105 mm
Weight: ~1265 g
Acc. to standard: CISPR 22, Annex D.9; CISPR 32, Annex G.9
