Loop Dimensions x: 50 × 50 mm
Loop Dimensions y, z: 150 × 50 mm
Number of turns: 40
Mechanical Dimensions: 166 × 81 × 60 mm
Mounting Holes: Ø 8.5 × 37 mm
Mounting Hole Spacing: 145 mm
Terminals (female): 3 × SMA
Nominal Frequency Range: 10 kHz – 100 kHz
Usable Frequency Range: 10 kHz – 1 MHz
Inductance x-Loop: 205 µH
Resistance x-Loop: 8 Ω
Capacitance x-Loop: 95 pF
Resonance Frequency x-Loop: typ. 1.15 MHz
Inductance y-, z-Loops: 450 µH
Resistance y-, z-Loops: 16 Ω
Capacitance y-, z-Loops: 120 pF
Resonance Frequency y-, z-Loops: typ. 0.69 MHz
Weight: 440 g
