Frequency range: 1 GHz … 6 GHz
Usable frequency range: 10 MHz … 8 GHz
Pulse duration at 10 MHz: approx. 60 ns
Pulse duration at 100 MHz: approx. 7 ns
Pulse frequencies: 10 MHz, 100 MHz
Nominal impedance: 50 Ω
Connector: N-type (female)
Frequency error: max. 50 ppm (typ. 20 ppm)
Stability of the output level: ±1 dB
Power supply: 6 × NiMH cells AA
Typical current consumption: approx. 150 mA @ 100 MHz, approx. 100 mA @ 10 MHz
Operating time with a full charge: approx. 8 h
Indication of the charge state of the battery: Dual-color LED
Dimensions milled housing only (without connector, knob or feet) W × H × D: 200 × 69 × 39 mm
Overall dimensions W × H × D: 214 × 68 × 67 mm
Weight (incl. battery): approx. 690 g
